Shot Blasting Machine in Pune

Shot Blasting Machine in Pune Model No P7 300
Shot Blasting Machine Blasting Hose Length (Mtr) 5
Shot Blasting Machine Blasting Hose ID (mm) 19
Sandblasting Nozzle (mm) 5,6
Shot Blasting Machine Cleaning Rate (m²/hr) 5-7
Shot Blasting Machine Metallic Storage Capacity (Kg) 300



Shot Blasting Machine Manufacturers in Pune

Sand blast is the most significant shot blasting machine manufacturers in Pune. Shot Blasting Machine is a technique that is used to smooth a surface with the help of high-velocity abrasive media like aluminium oxide, cut wire shots, glass beads, steel shots, etc. The shot blasting machine method helps in obtaining the cleaning and surface preparation for the secondary finishing operations such as painting, thermal spray coating. Rust and containments are the obstacles in the path of production.

A shot blasting machines are used to increase good quality products we need to remove these impurities at an early stage otherwise these impurities decrease the life of the substrate. So, we got a technique named Shot blasting which is a process of removing various kinds of impurities from the surfaces of the components.  The blasting process is done on the parts before coloring, painting, and thermal spray coating, etc. so that no impurities are left behind on parts. Shot blasting machine in Pune for sale provide at a low price compared to other shot blasting machine manufacturers in Pune for sale.

Shot Blasting Machines are is used in many industries like metal manufacturing, the aviation industry, the automobile industry, and many more. Shot blasting machine manufacturer in Pune provides two technologies namely wheel blasting and another one is air-operated blasting. Shot blasting machines depend on the size and shape of the equipment on which blasting is needed. We are one of the best shot blasting machine manufacturer in Pune, and we provide a shot blasting machine price for sale in Pune with the best quality.

Shot Blasting Machine Working Process

A shot blasting machine working on high pressure, and on high speed depends upon the type of blasting machine. In shot blasting machines blast media is thrown at a high speed in a highly controlled way. It removed the dust, paint, and contaminants on the surface with the help of the abrasive impact. The shot blasting process using compressed air for propelling the abrasive media on the equipment with high velocity.

Shot blasting machine manufacturers in Pune provide different types of blasting machines with manual and automated systems. Automatic shot blasting machines are becoming possible after the introduction of the centrifugal wheel blasting machines. Wheel shot blasting machine is more productive than compressed air and achieves a better and more uniform finishing.

Types of Shot Blasting Machine

  1.  Wheel Shot Blasting Machine
  2.  Air-operated Shot Blasting Machine

Wheel Shot Blasting Machine

Wheel shot blasting machine is direct converts electric energy into kinetic energy by rotating a Blast wheel at different RPMs with the help of an electric motor. In the wheel shot blasting machines the capacity of any blast wheel is high. A wheel shot blast machine uses high-velocity cut wire shots, and steel shots to clean or smooth the surface. For loading, unloading, and conveying the components many accessories are used.

Air-Operated Shot Blasting Machine

An air-operated shot blasting machine is available in both open and close. In the shot blasting cabinet, the blast shots are pneumatically accelerated by an air compressor and projected by a sandblasting nozzle onto the component for the blasting process. For special application and soft material components, a mixture of shots and water called slurry can be used, this is called a wet blasting machine.

In shot blasting cabinets the sandblasting nozzle can be installed in a fixed position or can be operated manually or by automatic nozzle accumulators. The blasting task defines the choice of the blasting media and shot blasting machine in most blasting operations any type of dry or free-running abrasive media can be used.

Advantage of Shot Blasting Machine

Removing Corrosion: A shot blasting machine helps to remove rust and corrosive materials, and other foreign containments from the surface. Also, use for removal of corrosive builds holds rust, chemical stains, faded paint, mill scale, and heat treatment scale, etc.

Surface Preparation: Shot blasting is the most efficient and effective method to prepare a metal surface before paint or zinc wire coating and make them smooth.

  • Shot blasting provides a solid bond between the blasted surface and the protective coating.
  • Blasting pattern accuracy is high.
  • Shot blasting machines increase the lifespan and the duration of future thermal spray coatings.
  • Revealing any surface defects.

The Environment: Shot blasting is one of the best environmentally friendly, and less hazardous options for corrosion removal and surface preparation for painting or coating.

  • No hazardous chemicals are used.
  • No hazardous acids.
  • The only cleanup is physical pellets.
  • The process only uses blasting abrasion to polish the metal surface.
  • Shot blasting Minimizes the cost of operation & maintenance.
  • Shot blasting excludes the usage of non-eco-friendly and harsh acids & chemicals.
  • Shot blasting machine provides higher production rates and blast pattern accuracy.
  • Powerful vacuum and dust collection systems are available to sweep away the dust in shot blasting cabinets, and shot blasting rooms.

Application of Shot Blasting Machine

  1. For cleaning of non-metals & metals like iron, steel, forgings, non-cast parts, and many more.
  2. For mechanical surface preparation and cleaning of sheets, wire, rods, coils, etc.
  3. Shot peening in blasting is done to change the mechanical properties such as increasing resistance to fatigue of springs, gears, etc.
  4. Preparation of surfaces for further operations like paint, color, thermal spray coating, etc.

Shot Blasting Machine Price in Pune for Sale

Sand blast is a leading manufacturing group of shot blasting machines in Pune for sale at a low price. Shot blasting is a required process before painting or applying a protective coating layer on the surface. Shot blasting machine manufacturer in Pune is available at low prices as compared to other shot blasting machine manufacturers. We also manufacture and supply portable shot blasting machines, sand blasting machine, thermal spray gun, flame spray gun, wire flame spray gun, arc spray gun, glass beads, copper slag, steel shots, metalizing wire, zinc wire, pinch valve, mixing tube, sandblasting nozzle, etc at a low cost.
